VDOG Variable Angle Gear - Cast Option

VDOG Variable Angle Gear - Cast Option

2019 SEMA Best New Street Rod Product and Best Engineered New Product

 The VDOG™ has a cast aluminum housing and the output shaft is ¾-36 for compatibility with universal joints. The unit is gear driven without any chains or sprockets. It can be mounted in horizontal or vertical positions - ideal for Cab-Over vehicles, T-Buckets and specialty builds with big motors and tight firewall clearance.

Designed and built in the USA!


• 90° gear box with a 35° variable angle shaft

• Articulating ball design for maximum adjustability

• 1:1 ratio to maintain rack and pinion or steering box gear ratio.

• Multiple mounting feature – can be mounted vertically or horizontally

• All Gear Drive – No chains or sprockets

• Available Billet Housing Option. Contact Sales for information

• Cast model can be powder coated any color from our RAL deck!

• Made in the USA

Check out what our friends at Modern Rodding were able to accomplish using our Flaming River VDog and our Microsteer kit.

More Information
Weight 10.000000
Shipping Dimensions 6" x 8" x 8"
Warranty 1 Year
