The Big Switch with Removable Key

The Big Switch with Removable Key

The Big Switch with removable laser cut, stainless steel key enhances the security and safety features available with the Big Switch. This unit is rated at 250 amps continuous service and 2500 amps for 5 second intervals (12V / 24V) It is a heavy duty, waterproof switch. The removable key feature is ideal for construction, farm equipment and passenger cars. An absolutely essential theft deterrent.

Part No. FR1009
Max Continuous Current 250 Amps
Max Surge Current 2,500 Amps (5 seconds)
Environmental Protection Rating IP65
Water Resistant Yes
Operating Temperature Range -40°C to +80°C / -40°F to +176°F
Contact Terminals Silver-Plated Copper
Contact Hardware Nickel-Plated Brass

Note: Terminals on battery disconnect switch are a live part of the electrical system and should be treated just like battery terminals. Covers are recommended, but not included. Contact vehicle manufacturer to determine proper placement and suitability to your application.

More Information
Weight 2.000000
Shipping Dimensions 3" x 8" x 9"
Warranty 90 Day
FR1044 The Big Switch Instructions
