The Big Switch with Lever Kit
SKU
FR1003-2
$149.43
The Big Switch with Lever Kit
The lever kit allows for remote actuation of the Big Switch. The kit includes an 18" long, aluminum threaded rod, T-handle, mounting bracket and necessary hardware. A "push off" decal is included. The Big Switch is a heavy-duty battery disconnect switch rated at 250 Amps of continuous service in 12V, 16, and 24V systems. The Big Switch is manufactured with silver plated electrical contacts and a sealed, water resistant design that is able to withstand the most severe operating conditions.
| Part No. | FR1003-2 |
| Max Continuous Current | 250 Amps |
| Max Surge Current | 2,500 Amps (5 seconds) |
| Environmental Protection Rating | IP65 |
| Water Resistant | Yes |
| Operating Temperature Range | -40°C to +80°C / -40°F to +176°F |
| Contact Terminals | Silver-Plated Copper |
| Contact Hardware | Nickel-Plated Brass |
| Additional Notes | Approved for NHRA/IHRA competition use |
| Available Stud Length | 0.775" (approx. 25/32 in.) |
| Extension Handle/Lever | Yes |
| Extension Part No. | FR1006 |
| LED On/Off Indicator | No |
| Lock-Out Capability | No |
| Max Tightening Torque | 11-13 ft. lbs. |
| Mounting Bracket Included | Yes |
| Mounting Bracket Part No. | FR1007 |
| Stud Diameter | M10 |
| Terminal Covers Included | No |
| Terminal Covers Part No. | FR1003TM (pair) |
| Voltage | 12V/24V |
| Weight | 3.000000 |
|---|---|
| Shipping Dimensions | 6" x 4" x 21" |
| Warranty | 90 Day |
