Tilt Columns • Column Installation
INSTALLING THE CANCELING CAM (KEY COLUMN)
1. Install the large 5/8”aluminum
spacer over the column shaft.
2. Next install the Canceling Cam
Spring over the column shaft and
down to the 5/8” aluminum spacer.
3. Then, slide the Canceling Cam
over the column shaft and
canceling cam spring.
For proper operation of the canceling
cam, align the canceling cam stem
between the 10 and 11 o’clock
position. (figure A )
4. Place the final 3/16” aluminum
spacer over the column shaft and
down to the canceling cam.
5. When installing your steering wheel
adapter, tighten the retaining nut to
50 ft lbs.
IMPORTANT: (FOR KEY AND NON-KEY COLUMNS)
A spring-loaded horn contact connects to the underside of the canceling cam.
When connecting the canceling cam to your horn button, please note:
The BLACK WIRE is only designed for momentary ground to trigger a horn relay.
DO NOT connect voltage to the BLACK WIRE, or permanent damage to the
column wiring or other components will occur.
