Install the original dash bezel and
column mounting bracket over the new
split ring spacer onto the new Flaming
River® Tilt Column.
Column Includes steering box shaft
adapter for easy installation to the
original steering box.
Cruise Control Kit
This aftermarket cruise control kit, with a GM
style lever, can be installed on your Flaming
River Tilt Column. Note: For vehicles with noncomputer
engines only. Order this when you
order your Flaming River column and we will
install it for you. Non-returnable.
Female Wiring Adapter FR20118
Tilt Columns • 55-57 Thunderbird
A B C D E F G H J K L M N P
Connecting the Electrical System
Wiring Circuit Pin Location Column Wiring
Brake Light Switch
Right Rear Turn Signal
Left Rear Turn Signal
Turn Signal Power
Right Front Turn Signal
Left Front Turn Signal
Caution: Before disconnecting your original
steering column wiring harness please verify
each wire color and function. Some wire colors
may vary from year to year.
Hazard Note: Some vehicles did not have
hazards from the factory, so no hazard
power wire is present but can be added by
purchasing part # FR 20118-1
